Sunday, May 6, 2018

My settings for the Sony A7M3

Recently my friend Jim Palik moved from Canon to Sony after over 40 years with the big gun. At 75, he says, you start to think about how much weight you are carrying around and the Sony mirrorless camera is much lighter than the 5D Mark II. So we went down to his favorite camera store and he bought the A7M3, a Sigma adapter for his Canon lenses, a Sony 64 GB SDXC memory card and an extra battery. Now he is ready to get out and play!

But first I promised to tell you readers (and Jim) what settings I've decided to use for my camera - the menus inside and the customizable buttons and dials on the body.

First of all, I've never noticed that the camera added movement to the picture when it was taken on a tripod with Steady Shot on. Therefore, I'd recommend simply leaving on the Steady Shot. If you are using a lens with stabilization in it, you can easily turn that off if you like, but the chances that I would forget to turn it back on are so great that I would prefer to just leave it on.

For the first time, I've chosen to change two focusing settings with this new Sony camera. The focus peaking feature has been highly praised over the years and I've usually had it set to High and turned the color to Red. However, that was using the AF-S focusing mode. With this camera I've begun using the DMF function and have turned off the (distracting) red focus peaking. The camera focuses and then moves to manual focus mode so that you can check and perfect the focus point if necessary.
Why did I do this? In the past it was somewhat bothersome to do this because when I adjust the focus manually, I have the camera zoom in on the subject so that I can see it better. However, the zoom area is not always where I want to focus, so I had to fiddle around with the toggle switch and by then the camera had either zoomed back out or the subject had moved. But with the new touch screen, it is easier to move the focus area to the desired spot, even while you are looking through the viewfinder.

However, when I am shooting sports or some other active subject, I move to AF-C and can easily focus-follow the moving person or animal with a quick click of the button inside the big control wheel. I have set C1 to Focus Mode to make this change easily.

Speaking of zooming, at the baseball game last week I often opted to shoot in the APS-C mode from the center ("sweet spot") of the sensor, resulting in a 10MP image which is basically a digital zoom. The advantages here were three-fold: I could crop the picture in-camera, the images wouldn't take up as much space on my hard-drives and the buffer didn't fill up as quickly. I have the AEL button on the back (top-right) of the camera set to one-click zoom because in the menu (Camera 1, first page) I have set APS-C/Super 35mm to "Auto" and "Manual: On". The AEL butt on is then set to "Full Frm Sel."

So where is my AEL button? That is on the front under C2. I wanted to be able to zoom and click the shutter at nearly the same time, so I set the zoom button to the back. But for AEL, I can have that up front. I prefer AEL toggle so that my other fingers are free to make other adjustments after I've made that all-important exposure adjustment.

I usually shoot in Wide Focus Mode, making adjustments later manually. Since I change this setting relatively rarely, I have it on the C3 button, which requires a bit more fumbling about to find and change. Zone focusing is a good choice when simple compositions such as landscapes are in front of your lens. Simply jog the Multi-Select Button left or right, up or down to change the zone. The same works for the Flexible Spot (mine is set to "Medium") or the new expandable flexible spot.

When I want to shoot in Manual Focus mode only, I click on the AF-ON button on the back, which is pre-programmed to turn the automatic focus on and off anyway. I'm used to having this function there, so I don't have to think about it any more.

The trash can/C4 button is also customizable. I want to take advantage of the new touch screen for focusing. There are times, however, when I don't want to have it on. So I simply press C4 and it turns off.

The next thing I have programmed is the Multi-selector, which I press to set the Eye focus. I haven't used it as much as I had originally hoped to, but when I do more portraits, I'm sure I'll be turning it on more frequently.

Finally, the control wheel is set like this for me:
Left is Drive and Right is ISO. Why override the icons painted on the camera body here if there is no good reason to? I don't have to change ISO with this camera very often; it is usually set to Automatic 100-8000 because I've found everything within this range to be good. I might raise the minimum ISO to 200 or 400, but that's just out of habit. Having the Auto ISO Shutter Speed minimum set to Fast or Faster does the same thing.
Pressing the bottom of the control wheel changes my silent shutter function. Read all about the pros and cons of that here. That post also explains when I want to turn it off (or back on). I've recently realized, however, that when using the LA-EA4 adapter with the A7iii, the set-up makes a click when you take a picture. The shutter is no longer silent.
The top of the control wheel cannot be changed. It always changes what the display looks like: graphic display, all info or none, level, histogram, blank (off - such as for night shooting). These settings can be changed on the second Camera menu on page 6 (DISP Button). Set the display and viewfinder to show different things if you so wish.

My Function Menu looks like this:
Top row -
Auto ASP-C (in case I end up accidentally zooming too often, I can easily turn off the function)
ISO Automatic Shutter Speed (usually set to FAST)
Focus Area
Metering Mode (usually matrix)
Picture Effect (rarely used, but it is otherwise hard to find and turn on; only relevant when shooting JPEGs only)
Live View Display (important to turn off when using a flash)

Bottom row -
DRO (usually AUTO, but unnecessary when shooting RAW)
Priority Set in AWB (Standard; read more about this setting improvement here)
White Balance (AWB, though I sometimes change it to Flash when shooting primarily with a flash)
Picture Quality (RAW)
Creative Style (Standard tends to be the best, but I think you get a bit more light if you set it to Light in darker situations)
Grid Line (usually on Thirds, but turning it off can give you a feeling of freedom with your picture composition)

Furthermore, I stay in airplane mode unless I want to use my phone to transfer the GPS coordinates to the metadata in the pictures I'm shooting. I have tried this and it worked perfectly. Why don't I do it all the time? It drains both batteries (phone and camera) if on all the time.

Sunday, April 15, 2018

Shooting sports with the A7M3

 I've already talked about using the silent shutter for concerts and the caution one must exercise with moving objects or while panning. Here is another good example of when to be careful when choosing the silent shutter.

Yesterday I was standing in the visiting team's bullpen shooting pictures into the glorious afternoon light. I had a great view of the right-handed batters and the infield. I didn't want the players to be distracted by my shooting, so I went silent most of the time.

As you can see in the two photos above, I was panning with the runner, which resulted in everything behind him being slanted in the direction the lens was panning, if the person or object was either not moving, moving slowly or not at all. The first picture has lots of vertical lines which call attention to themselves in a case like this. The second one isn't so bad.
The one below, in contrast, was also taken with the silent electronic shutter, but the ball is moving so slowly that it still appears round and the fielder in red has normal proportions. Using the silent shutter still has two main advantages: it draws less attention to your camera and yourself at a game like this and it doesn't wear down your shutter mechanism.

The light dwindled as the second game continued. I started shooting at 4 pm at around 800 ISO so that I could get some fast shutter speeds (between 1/500 and 1/2,000). I was using the Sony G f4.5-5.6/70-300 at around 200mm most of the time, but this is a lens I like to used stopped down a bit, so I needed the extra ISO. No problem for this camera.

The Hornet's catcher gets hit by a deflected pitch in the right wrist. He moved out to left field to give his injury time to heal.
I took the first half of the pictures in JPEG and, as a test, switched to RAW at the end. I much preferred having the information available in the RAW files when doing the little bit of post-processing which was necessary. The details came out much better in the RAW files, which is why I usually shoot RAW.
Sometimes I switched to APS-C mode for a 1.5x magnification with the touch of a button (more on my preferred settings in the next blog post). I did this mainly because I knew I would neither need nor want huge files; 10MP would be enough. In addition, the files can be saved to the memory card much more quickly this way, not that I had a problem with buffering - I simply didn't take that many in one burst.
I also took the first JPEGs with High ISO Noise Reduction set to "Low" and then the others at "Normal", but didn't notice any difference between the two. Most of the best pictures were taken at around 1/1,000 sec and 1,000 ISO. The aperture stayed at around 5.6-6.3 most of the time, though I did pump it up to 7.1 when I didn't need the extra speed.

This was taken at 250mm x1.5 magnification using the APS-C area of the sensor.
It was nice working with the long lens again. Shooting at 1/1,000 - 1/2,000 sec., I had no problem with camera shake, even though I was effectively shooting without a tripod and at 300-450mm much of the time.
The last thing I played with during the game was the video function, thinking I'd take some frame captures of the action. It just so happens that I got some footage of some of the most exciting parts of the game. Below, you see the opposing pitcher getting hit by the ball. Then he took off for first base but stopped when he saw the ball being thrown home to tag out a runner. The catcher missed the throw but then got the second runner out. A real bit of excitement in what many Germans consider an incomprehensible and boring game! I thought the whole thing was thrilling. There were a lot of hits, good pitching and even an incident of "catcher interference", which I had never heard of!

Below: A slide into home plate captured on video, made into a print with Lightroom. The camera also has a function for doing this. Here is the difference in quality between the two processes:

That's right; no difference. Here is the original 4K video. Enjoy!

Friday, April 13, 2018

Getting accurate exposures with the Sony A7M3

1/1600 sec. at f7.1 and 100 ISO - Easter Sunday sky
Coming from the A700, A77 and A7, I've noticed loads of improvements in the Sony mirrorless segment since October 2011 and December 2013 with this newest camera, the A7M3.

Today I want to touch on three points regarding picture quality. One is especially important if you want to shoot JPEGs. There have been improvements in the white balance menu and settings.
I nearly always have my white balance set to "Automatic" (AWB) because when shooting RAW you usually change the colors a bit while post-processing anyway. And yet Sony realized that shooting inside as much as you would with such a high-ISO monster, you might want to tell the camera's computer exactly what kind of automatic output you prefer. So they have come up with a way to prioritize the tone when shooting under certain lighting conditions. You can have the traditional AWB working; you can prioritize the ambient lighting (creating a warmer color cast); or you can set it to "white", resulting in a cooler tone. I think this is a great tool!

1/30 sec at f6.3 and 4000 ISO - the Freiburger M√ľnster
Furthermore, there are 16 different white balance pre-sets, all of which you can tweak to your heart's content - more red, more green, blue or yellow. When shooting JPEGs, set your white balance to the room's light temperature by pointing the camera at a white piece of paper that is lit with the same ambient lighting as your motif. While your camera is set to the "Custom Setup" function (the last one in the WB menu), take a shot with the center circle pointed at the white paper. Then assign that specific WB to one of the three custom WB settings and you are good to go - until you move into another room or someone turns off the lights and decides candlelight is more romantic!

1/30 sec. at f4 and 1250 ISO - Brass workshop
Second, there are two settings that help you nail the right exposure on the motif in your picture. The first one detects the brightness on faces in your shot when your metering mode is set to "Multi-segment", which is the setting you'll normally want to use. That setting together with the spot metering coordination seem to be very helpful tools when shooting events with tricky lighting situations (bright lights in the picture, backlighting, etc.).

Spot metering is the way digital photographers measure the amount of light needed for a perfect exposure on the chosen motif. No longer do we have to run up to the model or mountain top and hold up a lighting meter to get a good reading of the exposure! This camera can pick a spot and determine how much light is needed for a normal exposure. With the new A7M3 you can coordinate the spot metering point with the focus area even when it is not in the middle of the focus area.

Below is an example of a situation in which I wish I had still been shooting either with both RAW + JPEG or in the spot-metering mode. My cards were filling up, though, and I was taking fast sequences of shots of these birds, so I switched to JPEG only. Unfortunately, the beautiful dark feathers of this hawk were no match for the bright background, which the camera also figured into the "Multi-segment" metering equation.

1/3200 sec. at f4 and 100 ISO
As with the A7, I've had situations where the A7M3 took an absolutely wrong reading of the light and overexposed the scene by a whole stop or two. I never had that with the earlier cameras. However, the electronic viewfinder lets you know immediately that the exposure is wrong. My experience shows that this usually happens after you have just turned on the camera and want to take a picture right away.

So you can set both the exposure and focus areas for the shot you are about to take. Speaking of the focus area, you can set the camera to prioritize focusing on faces when in the wide or zone focus area settings. That's often a good idea when you are shooting people in landscapes, but look what happens when you aren't!

Both photos were taken at 1/640 sec., f5 and 400 ISO - Sea lion feeding time at the Wilhelma
Here is, of course, what I really wanted to focus on:

Finally, for those of you who don't want to guess which exposure might be best in the end, you can set the drive to "Bracket". Now this is nothing new except that Sony has now expanded your bracketing capabilities from three or five images to nine! Together with the 14-bit uncompressed RAW files, this ability to capture a nine-image series of varying exposures will enable you to put together some incredible landscapes! On the other hand, I have seen few situations where I've needed the bracketing. A RAW file is so flexible that you can usually brighten the shadows and tame the highlights to have as good a result as a three-shot, four-stop bracket could give you.

1/500 sec. at f8 and 320 ISO - Vineyards in Rotenberg

Thursday, April 12, 2018

Improvements in Lightroom

1/320 sec. at f5 and 2500 ISO - developed in Lightroom Classic from the Sony ARW file
Just in time for working with the new Sony A7M3, Adobe has updated its Lightroom software, not only to include RAW (Sony's ARW) profiles for that new camera but also to add several new features and a couple of useful tweaks to the interface.

Same shot developed in Lightroom Classic from the in-camera jpeg, which had NR set to "Low".
After waiting for three weeks for Adobe to come up with a RAW converter for the new camera, I was very pleased to see the results of batch processing in the case of this theater production. The lighting was uneven, concentrating on the center of the stage and falling off quickly towards the edges. I took care to expose for neither the brightest nor the darkest faces. Still, there were big differences in the luminosity in the faces, as you can see from these two photos below.

Straight out of the camera RAW

"Auto tone" brought down the highlights, punched the shadows and added vibrance and a bit of saturation.
All in all, this auto tone is a good place to start. Sometimes it'll add clarity to the photo as well, which can add noise, as does the boost to the shadows, so keep your eyes on those sliders.

Now with the newest version of Lightroom, you have the choice to create a common look among all the pictures in a series such as the 400 pictures I took of this performance. If you don't have a set aesthetic with you like to bring to your pictures, you can try one of a number of color or black-and-white presets. Of course, presets have been around a long time, but now you can hover the mouse over thumbnails in the right-hand panel (F8) to see what the image will look like after you apply the preset.

Your camera already has several color presets for jpegs (the bottom three thumbnails above), but Adobe has added new ones, including Vintage, Modern and Artistic. Different strokes for different folks - but also for different sets of photos. There are also 26 B&W presets which basically increase or decrease a certain native color one at a time or in conjunction with another one.
If you know what you are doing, you can create your own presets (color, B&W or otherwise) to increase the speed of your workflow. I use ones I've created for bringing out detail in a blown-out sky, for increasing the detail in a scene, for adding some light to people's faces and for popping a landscape. Plus I have my "Highlights" slider set at -15 because I notice I often want to retrieve some detail from the brightest areas of the photo.

1/60 at f4 and 8000 ISO - developed in LR from the Sony ARW file

This was developed from the in-camera jpeg. It was difficult to achieve a natural looking skin tone because the jpeg (perhaps on account of the high ISO) offered only patchy reds and yellows on her skin.

1/320 sec at f5 and 2500 ISO - here the RAW file has a lot of detail and little noise

The jpeg doesn't have quite the smooth gradations in the colors of the face and it loses some detail on account of the in-camera "Low" noise reduction.

This version was processed in Sony's Image Edge Editor, which created yet again different skin tones.
Another thing that was supposedly improved in this version of Lightroom is the face recognition. I say "supposedly" because, first of all, it seems to have lost all the data I had painstakingly stored in the catalog and, secondly, because Alane looks nothing like a head of salad (see below). Yes, the program may find more faces than it use to, but what good is it if it can't match the faces? I don't use this feature much anyway.

Friday, April 6, 2018

Battery life of the Sony A7M3

My experience after three weeks with the camera

Battery for the A7M3, which lasts seemingly forever!
I'll get right down to one of the biggest improvements in the newest Sony cameras: the battery life has more than doubled. The NP-FZ100, as you may assume from its predecessor's name (NP-FW50), is larger and much stronger than what we had in the earlier models. The Alpha series before the A7 had the big, strong NP-FM500H, which lasted a couple of days in the A700 and nearly a day in the A77, Live View draining the battery more than on the A700.

Battery for the first A7 cameras, which lasts a couple of hours.

Battery for the A100-A77, which lasts a couple of days.
I have three of the smaller batteries for my A7 and usually had to change them after an hour of shooting when the thing went down to around 17%. I never bought the external charger, figuring it was easier to just have a few spares in my pockets.

The relative sizes of the Sony batteries tell you a lot about how long they last.
Last night I started shooting a theater production at 95% on my A7M3. After three hours and nearly 500 shots it was still at over 40%.
When I bought the camera on March 12, I had been fretting that I'd be powerless until replacement batteries become available at the end of April. But so far, so good.

I must add one caveat, though. It takes a long time to fully charge the battery, so plan on recharging over night. If you have to shoot in the afternoon and then again in the evening, a two-hour charge will put you back up into the safe zone so you should get through the evening ok!

Tuesday, April 3, 2018

The Silent Shutter of the Sony A7M3

Take pictures at a concert unobtrusively with the silent shutter function.

One thing I liked most about the Sony A7M3's technical specifications was the silent shutter. At weddings, speeches or at (classical) concerts, having a silent shutter can be a blessing. However, I've discovered two drawbacks to using it so far.

But first the good news!
It is indeed absolutely silent. Unlike the Sony RX100 series and most other point-and-shoot cameras which make a slight sound when capturing a scene, the A7M3 is as silent as your cell phone's camera (assuming you've turned off the annoying fake shutter sound!).
Furthermore, the silent shutter is as fast as the regular physical shutter. That can be tricky if you are used to hearing the shutter click and taking the sound as a cue to stop shooting. If you are in continuous shooting mode (as I was when I took my first shots with the camera), you can easily take 20 pictures before you realize what you've done.

My first photos with the A7M3. Set on silent shutter mode, I didn't realize I had taken 26 photos until two seconds later.
Now the bad news: There are two drawbacks to the silent shutter.
The camera can normally detect flickering fluorescent lights, timing the exposure to moments when the flickering will have less of an impact on the resulting shot. To quote from the help guide: "In continuous shooting mode, the shooting speed may slow down or the interval between each shot may become unequal." So if you are shooting at 1/80-1/250 in an indoor, florescent-lit setting using the silent shutter, you may see stripes on your photos (see below). To avoid this, turn off the silent shutter.
1/200 sec, at f4.5 and ISO 4000 (silent shutter ON)
Interestingly, the stripes are always parallel to the long edge of the frame and have nothing to do with the "light falling from above".

1/250 sec, at f5.0 and ISO 2500 (silent shutter ON)
The second drawback to using the silent shutter function will sound familiar to videographers and to those of you who read about optimal shutter speeds when filming. At a bird show last weekend, I panned the camera as I tracked an owl flying over the viewers' heads from its perch to the falconer's glove. When I viewed the pictures on my computer monitor, I realized that the heads of the audience members were skewed.
The first photo below was taken using the mechanical shutter. The heads of the audience members are all shaped normally. All three pictures below were taken at 1/640 sec.

The next two photos show two things: On the one hand, the A7M3 can track a fast-moving target very well, even against a complex background. On the other hand, the rolling shutter effect distorts things that are not moving at the same speed as the camera's lens.

Heads in the crowd are leaning suspiciously to the right, a result of the rolling shutter effect thanks to the silent (electronic) shutter.
My judgement on the silent shutter is that one should use it in situations where you don't have to move the camera quickly, or where your subject is not moving quickly (see Gordon Laing's video about this phenomenon here) - it is still perfect for speeches and weddings, though, where the lighting is other than florescent!

When you are using the LA-AE4 adapter with Alpha lenses, the shutter causes a click in the adapter because the mirror flips up. So it is then no longer totally silent.

Finally, I was riding atop a tourist bus in Luxemburg recently, shooting the interesting architecture in that city. There I didn't seem to perceive any problems with a rolling shutter, though I was shooting in silent-shutter mode. The camera was probably staying put on one object for just long enough to avoid slanted lines.

1/640 sec. at f6.3 and ISO 200

1/1250 sec. at f7.1 and ISO 200

Tuesday, March 20, 2018

Sony A7iii (a.k.a. A7M3)

1/400 sec., f4, 500 ISO
The follow focus on this camera works well for you once you've figured out the best way to use it!
I'm really excited about this camera, so I'm gonna write more about it. The lens with which all these shots were taken (Sony FE 4/24-105 G OSS) is also terrific.
If you are here, then you've watched some of the video reviews on this camera. I'm not going to make a video review; I'll let you skim over this till you get to the juicy part you want to read about. It goes quicker for you that way.

This is a still excerpted from a 4K video taken with the A7iii
I'm not much of a fan of the video formats: Introductory music and teaser - Photographer introduces himself and his location - He/She says what he's going to cover in the video - He makes some jokes, usually with friends (usually a "guy thing") - (This next part I hate:) He tells you that this new, "basic" camera has a lot of the same features as the much more expensive A7riii and/or A9 - He wonders how Sony could afford to do that - He tells you what is missing (only 10fps, no lock button on the PASM dial, etc.) - Then he gets to the point half-way through the video. Half of the information will be so basic that your grandmother could have told it to you - There will be one tweak or hint that will be useful. Unfortunately, you'll forget it after a couple of days and not know which of the dozens (soon to be hundreds) of Sony A7iii videos you saw it in. Luckily, you can always come back here to read about the camera!

In my last blog I said I'd pass on my real-world discoveries to you. First, two tweaks that you won't find in the manuals:
1. To stop the Eye-start AF (developed by Minolta in 1992) from blacking out your display when the strap or your fingers get too close to the viewfinder, simply pull out the display a few millimeters and you won't have the problem any more.
2. When reviewing the pictures you've just taken, quickly tap twice on the display to zoom in and then move the photo with your finger to view the part you want to see. Tap twice again to return to the normal view.

1/250, f5, 100 ISO
It is a shame that this JPEG is so muddy. I think it may, however, be due to the fact that I had the noise reduction set to "Normal", which would even affect the low-ISO images.

1/320 sec., f5, 100 ISO

1/50 sec., f4.5, 6,400 ISO
The detail on the building is pretty much lost at this ISO
and with "Normal" in-camera noise reduction.
That will be different when converting from RAW.

These two photos were taken at 1/80 sec., f4 and 4,000 ISO

Count the whiskers! It was nearly dark when I took this picture at 1/20 sec., f5 and 12,800 ISO

The thing I first fell in love with here was the ability to set minimum shutter speed settings while in Auto ISO mode. I'm sure I asked for it in some forum years ago. And here it is!
So you are inside shooting an event and want to get the best quality photo but need to maintain a certain shutter speed to keep from capturing blurry hand and head movements. You set the ISO ASS (Auto Minimum Shutter Speed) accordingly: Slower, Slow, Standard, Fast, Faster. Or set it to the specific shutter speed you need/prefer - anywhere from 30" to 1/8000"! That is an amazing plus for this camera!

1/50 sec., f4, 2,000 ISO

1/100 sec., f4, 4,000 ISO
Pretty clear bell on that trombone even at this high setting!
Last time I wrote that I'd tell you about the pros and cons of the touch screen. Well, in the mean time I have not come up with any cons except that you might smear the display with your fingers, but even that hasn't happened yet with mine. I thought my nose would continually move the focus point when I hit the display, but that has yet to happen. To be on the safe side, though, I've set the active part of the touch screen to the right-hand 1/4 and then have the movements set to "absolute position". This way I can easily change the movable focus point with your thumb. (More on your thumb in the next post.)

Saving some really good news for last today:
First, the new NP-FZ100 battery life is amazing. I shot a two-hour concert and was still at 78%. I don't need any more than that, although I will want a second one in my bag (€90 - ouch!) when I'm out all day. With the tiny old NP-FW50, I'd have been on 17% and reaching for a new one.

1/250, f4, 8,000 ISO
That is amazing detail for this setting!
Second, the start-up time for turning on the camera is lightning fast. I don't know how the engineers managed it this time (and not in previous iterations!), but it's a pleasure.

Next time I'll write a bit about exposure and white balance settings that are new and improved in the A7iii. Let me know if you have any specific questions regarding this camera, and I'll try to answer them for you.
